All kind of roller test & demo stand (Rollenprüfstand)

@

       We are the Taiwan Model Train Club (TMTC), we have played and sold the model trains since 1995, We have sold many kinds of the roller test stand to our customers by a few brands. While the time we have tested and studied all of the roller test stands, we found most of roller test stand is good but not perfect, so we did some research then created and improve the functions, structure and quality to let our roller test stand be the best in the world.

      Rail
Stand first "roller test stand" was announced in June 2013 then we innovated the all-new "roller demo stand" in 2014, the new roller demo stand was the first demo stand in the world , It's hidden all of the bearing trolleys under the track, This's vocational roller demo stand was design for demo your favor locomotives by dynamic. In 2015 we created another new roller stand called "easy test stand" it's designed for easier and more convenient to test your locomotives also it's hidden the bearing trolleys so it could be a roller demo stand too. 2017 we created N scale roller test stand, we have improved the structure to let it easier to use and let the shape more clear and elegance, Our N scale roller test stand will be the smallest and most function N scale roller test stand in the world.

     RailStand has a special design and got several patented, the structure is unique and precise. Please check and compare the RailStand roller test stand with other roller test stands, we believe you will be satisfied in our design and quality.

N scale roller test stand (9mm)
        RailStand N scale roller test stand will release soon, the new roller test stand was designed for the N scale (9mm track), we have made many tooling to improve the structure to let it easier to use and let the shape more clean and beautiful, Our N scale roller test stand is the smallest and most functions roller test stand in the world.
functions:
    - Supprot the DC power and Digital DCC system.
    - Use gravity principle to conductive without screw.
    - The structure was design for steam, electric, diesel... all kind of the locomotive.
    - Could be installed an overhead wire for testing the power through the pantograph of electric loco.
    - Able to install into the wooden base with acrylic display cover to be a demo stand.
    - Could be put into the KATO track layout to be a programming track.
    - Full power on the tracks.

    @
 TYPE Stand Long Bearing trolley FOR KIND OF LOCOMOTIVE
N-2838 283mm 8 sets for all kind of Amercain locomotives: Big Boy....
N-2184 218mm 4 sets for all kind of EUROPEN and ASIA locomotives

PS: Please click here to see more detail, more photos.
@
HO roller test stand (16.5mm)
        RailStand designed and made a brand new roller test stand for HO scale AC and DC system, It looks similar to the Marklin roller test stand but we have modified and improved the structure and insulation parts to let the roller test stand easier, useful and safer to test your model locomotive. RailStand has more designs and functions than other brands.

Special functions:
    - Use gravity principle to conductive without screw.
    - Could be simple installed overhead wire for testing the pantograph of electric locomotive.
    - Could install into the wooden stand with acrylic cover to be a demo stand.
    - Could be install into the Marklin, TRIX layout to be a programming track.
    - Easy to connect two RailStand to test the ICE, TGB, EURO star... high speed model trains.
    - Bearing trolleys aslo could testing on the layout tracks.

TYPE Stand Long FOR KIND OF LOCOMOTIVE
HO-5208 520mm for all kind of Amercain locomotives: Big Boy....
HO-3804 380mm for all kind of EUROPEN locomotives
PS: Please click here to see more detail, more photos and videos.

@
HO easy demo/test stand (16.5mm)
       In 2015, RailStand created a new generation roller test stand that you have never seen it. we have re-designed the bearing trolley and install total 56PCS bearings on the frame then put the bearing trolley between the two rails so you won't see the bearings. It will let you more convenience to put the locomotive on the tracks and you won't need to adjust the bearing trolley for the wheels you only need to do is just put the locomotive wheels on the track.
       The easy test stand support the DC(2 rail)/AC(3 rail) and pantograph conductive, it has hidden the bearing trolley under the track and you don't need to adjust the bearing trolley you only just put the locomotive on it. It allows you to install into the layout and be a programming track or wooden stand with an acrylic display case. This new easy test stand not only designed to test your model trains but also lets you demo your locomotives by dynamic. It suits to put on your home's shelves, cupboard or on the office desk. We hope you will enjoy running the model train any time and anywhere, please take look and enjoy our new innovation.

TYPE Stand Long  For kind of the locomotive
Customize any size for the best effect to demo your favor locomotives.
EZ-5201 520mm Big Boy, Y6b, Challenger, Norfolk & Western, L-4b....and all of the Europe and Japan locomotives.
PS: Please click here to see more detail, more photos and videos.


@
HO scale roller demo stand (16.5mm)
       In 2014 we are proud to introduce our new creative product roller demo stand,  it's similar to the roller test stand but our design hid all of bearing trolleys inside the track and every one bearing trolley are still adjustable. roller demo stand support AC&DC + Digital&Analog + Pantograph&Track and able to install into the wooden stand with the acrylic cover case. The special roller demo stand was design for the railway gallery, museum showroom to exhibit their model trains by dynamic, also It suits to put on your home's shelves, cupboard or on the office desk. It's unique and creative, please take look and enjoy our new innovation.

TYPE Stand Long FOR KIND OF LOCOMOTIVE
Customize any size for your favor locomotives perfect display.
DY-3764 376mm BR18, BR53, S2/6, MIKADO, Crocodile, C57, D62 ...
DY-5208 520mm BIG BOY, CHALLENGER, NORFOLK&WESTERN ...
PS: Please click here to see more detail, more photos and videos.
@
O gauge 32mm roller test stand (Rollenprüfstand SUPRO)


       We are a pleasure to introduce our new product "O scale roller demo/test stand" to the O gauge model train fans. Both are support 2 rails/3 rails, DCC/Analogy and put into our patent element to re-design the best O scale roller test/demo stand in the world.
       We will offer two kinds of sizes for the roller test stand and accept customize for your favor locomotive. @


TYPE Stand Long Bearing bracket FOR KIND OF LOCOMOTIVE
OT-8104 81CM (31.9") 4 PCS BR18, BR53, S2/6, MIKADO
OT-9508 95CM (37.4") 8 PCS BIG BOY, CHALLENGER, NORFOLK&WESTERN, Y6B
@ @
PS: Please click here to see more detail, more photos.
@
O gauge 32mm roller demo stand (Rollenprüfstand SUPR O)



       We are a pleasure to introduce our new product "O scale roller demo/test stand" to the O gauge model train fans. Both are support 2 rails/3 rails, DCC/Analogy and put into our patent element to re-design the best O scale roller test/demo stand in the world.
       We will offer two kind of sizes for the roller test stand and we accept to customize for your favor locomotive. @


TYPE Length Bearing bracket FOR KIND OF LOCOMOTIVE
Customize    any size ? for your favor locomotives (strong recommand)
OD-8104 81CM (31.9") 4 PCS BR18, BR53, S2/6, MIKADO
OD-9508 95CM (37.4") 8 PCS BIG BOY, CHALLENGER, NORFOLK&WESTERN, Y6B
@
PS: Please click here to see more detail, more photos.
@
1/G gauge 45mm roller test stand (Rollenprüfstand SUPR 1/G)


       In 2019, We are a pleasure to introduce our new product "1/G scale roller test stand" to the 1 gauge & G gauge model train funs. The full-function 1/G roller test stand are able to test all kind of the locomotives which the assemble tracks and pairs of the bearing brackets are adjustable and moveable also they are able to install into the wood base. Our 1/G roller test stand not only for testing but also for presenting your favor locomotive. They support the DC / DCC / live steam, no screw need so they are very easy to use.

TYPE Length Bearing breaket FOR KIND OF LOCOMOTIVE
Customize any size ??? for your favor locomotives (strong recommand)
GT-6003 60 cm (24") 3 PCS T3, BR85, BR89, C12... tank locos
GT-9204 92 cm (36-1/4") 4 PCS BR18, BR53, S2/6, MIKADO
GT-14008 1400mm (55") 8 PCS BIG BOY, CHALLENGER, NORFOLK&WESTERN
@ @
PS: Please click here to see more detail, more photos.
@
1/G gauge 45mm roller demo stand (Rollenprüfstand SUPR1)

       In 2015, We are a pleasure to introduce our new product "G scale roller demo stand" to G scale model train fans. Our hidden bearing set patent functions to re-design and re-assemble a perfect G scale roller test & demo stand. The G roller demo stand not only design for demo but also can test your favor locomotive. It also supports the DC power/live steam so you are able to test or demo your Live Steam and electric Motor locomotive both.
       We will offer three kind size and Customize for your chosee, but we are strong to re-command you to choice the customize for the best demo effect. @


TYPE Length Bearing bracket FOR KIND OF LOCOMOTIVE
Customize any size   ? for your favor locomotives (strong recommand)
GW-6003 60 CM (24")   3 PCS BR55, T3, BR85, BR89....
GW-9204 92 cm (36-1/4")   4 PCS BR18, BR53, S2/6, SNCF 241, MIKADO....
GW-14008 140 CM (55")   ? BIG BOY, CHALLENGER, NORFOLK&WESTERN
@ @
PS: Please click here to see more detail, more photos.

    We designed and made the roller test stand, roller demo stand, easy test stand. If you are interested in our products or If have any questions or any suggestions to RailStand, please click the RailStand to leave your message or please email: sales@trains.com.tw or call us 886-9-37848773 , PayPal accept .
